UCODE HSL RFID Card
- UHF RFID smart card with NXP UCODE HSL chip for fast, reliable long-range reading
- Fully passive, optimized for supply chain, retail, and library systems
- Supports bulk customization including UID encoding, logo printing, and personalization
- Complies with ISO/IEC 18000-6C, EPC Gen2 for global interoperability
- Wholesale orders with discount
The UCODE HSL RFID Smart Card is used for superior performance in ultra-high frequency (UHF) applications. Leveraging the advanced NXP UCODE HSL chip, this card is ideally suited for supply chain management and logistics where long-range identification is crucial.
Key Features:
- Extended Read Range: Capable of long-distance communication up to 7 meters in the US and 4 meters in Europe.
- Global Standard Compatibility: Fully compliant with ISO 18000-6C / EPC Class 1 Gen 2 protocols.
- High-Speed Data Transfer: Offers rapid data transfer rates for efficient operations.
- Memory Capacity: Equipped with 2048 bits of read-write memory, a unique 64-bit UID, and 216 bytes of user memory.
Applications
- Supply Chain Management: Tracks items from manufacturing to delivery with ease.
- Asset Tracking: Monitors equipment and vehicles in real-time, even in remote areas.
- Access Control: Automates entry detection and access granting for vehicles.
- Inventory Management: Quickly tracks the location and movement of goods.
Security
Built-In Security Features: Includes 32-bit access and kill passwords for secure memory protection.
Anti-Cloning Protection: The unchangeable 32-bit UID provides a basic layer of security against cloning.
Durability and Customization
Durable Construction: Made from high-quality, durable PVC or eco-friendly rPVC, resistant to bending, cracking, and water.
Branding Options: Supports high-quality, full-color printing for logos, text, and other branding elements.
Ordering Information
Bulk Order Friendly: Optimized for wholesale distribution with short lead times and competitive pricing.
Customization Services: We offer full-color printing, UID programming, and other customization options.
Ready to upgrade your operations with UCODE HSL RFID Smart Cards? Contact us.
Physical Parameters
- SKU: Zeal-1020
- Material: PVC / PET / PETG
- Size: 85.5 × 54 mm
- Thickness: 0.84 mm
- Surface: Glossy / Matte
- Printing Options: Offset, laser code, barcode, QR code or more
RFID Specifications
- Chip: NXP UCODE HSL
- Frequency: UHF (860–960 MHz)
- Protocol: ISO18000-6C, EPC Gen2
- Memory: EPC 96-bit, TID 64-bit
- Operating Mode: Passive
- Read Range: Up to 10 meters
Environment & Durability
- Operating Temp: -25°C to +70°C
- Storage Temp: -40°C to +85°C
- Water Resistance: Yes
- Durability: >100,000 read/write cycles
- Resistance: UV, wear, chemical
Performance & Security
- Data Retention: >10 years
- Unique Identifier: Pre-programmed TID
- User Memory: Optional
- Anti-collision: Supported
- Tamper-Proof Features: Optional
Please Note: Customization options may vary slightly depending on the card material. If you can’t find what you want from the following option, feel free to contact us and let us know your needs. We’ll get back to you ASAP after confirming with our engineers. And we will do our utmost to customize the card you desire.
Printing Method
Here are 3 professional printing techniques to bring your designs to life.- Silkscreen Printing: ideal for printing logos and icons. The colors are pure and it is suitable for projects that require bright colors, large areas of solid color, and high-contrast patterns.
- UV Printing: Bright colors, scratch-resistant, suitable for complex patterns and multi-color printing.
- Offset Printing：High color reproduction accuracy, suitable for complex multi-color designs.
Surface Finishes
We provide the following surface finishes to cater to different branding styles.
- Glossy Finish: Surface is smooth and shiny, with rich and bright colors.
- Matte Finish: Soft and non-reflective, with a premium touch.
- Frosted Surface: Similar to frosted glass, it is anti-slip and anti-fingerprint.
- Spot UV: Glossy coating on selected areas for emphasis and visual contrast.
- Hot Stamping (Gold/Silver): Shiny metallic effect, enhancing card’s texture and brand equity.
Functional Add-ons
Improve usability with functional features to match your application needs.
- Magnetic Stripe: Commonly used for access control, membership, or payment systems.
- Signature Panel: Ideal for cards requiring a signature space, such as staff or banking cards.
- Scratch-off Panel: Covers PINs or promotional codes for privacy and marketing.
- Hole Punch: Allows easy attachment to lanyards or clips, useful for ID badges.
Security & Personalization
Enhance brand exclusivity and anti-counterfeiting features for premium applications.
- Variable QR Code / Barcode: Custom unique codes for access, tracking, marketing, loyalty programs, etc.
- Serial / Embossed Numbers: Unique serial number per card, variable data.
- Laser Engraving Number: Non-erasable, enhance anti-counterfeiting level.
- Hologram: Enhance brand trust and provide strong anti-counterfeiting protection.
Custom Size
Besides standard CR80 cards (85.5×54mm), we also allow you to customize the shapes, thickness (0.2 – 0.8mm), and dimensions according to project needs.Custom RFID Chip
Choose the RFID chips by protocol, capacity, and functionality. We have chip with LF (125KHz), HF (13.56MHz), and UHF (860–960MHz) frequencies. Other chips are also available upon request.
Chip Type Protocol Capacity Anti-collision Function Frequency TK4100 / No No Read Only 125KHz EM4200 / No No Read Only 125KHz EM4305 / 512 bit No Read/Write 125KHz T5577 / 330 bits No Read/Write 125KHz NTAG® 213 ISO14443A 180 byte No Read/Write 13.56MHz NTAG® 215 ISO14443A 540 byte No Read/Write 13.56MHz NTAG® 216 ISO14443A 924 byte No Read/Write 13.56MHz MIFARE® Classic® 1K ISO14443A 1 KB No Read/Write 13.56MHz MIFARE® Classic® 4K ISO14443A 4 KB No Read/Write 13.56MHz MIFARE® Plus® S 1K ISO14443A 2 KB / 4 KB No Read/Write 13.56MHz MIFARE Ultralight® EV1 ISO14443A 48 byte No Read/Write 13.56MHz MIFARE Ultralight® C ISO14443A 144 byte No Read/Write 13.56MHz ICODE® SLIX ISO15693 896 bit Yes Read/Write 13.56MHz Alien H3 ISO18000-6C 512 bit Yes Read/Write 860–960MHz
Core Technology & Performance Questions
Q: What is an NXP UCODE HSL RFID card and why is it special?
A: The NXP UCODE HSL is a classic UHF RFID chip renowned for its exceptional, long-distance reading capabilities. It was designed for high-performance applications where read range and reliability are critical, such as in complex supply chain and logistics environments.
Q: What is the typical read range of a UCODE HSL card?
A: It can typically reach up to 7-10 meters (23-33 feet) under ideal conditions. The final read distance depends heavily on the specific RFID reader, the size and type of the antenna, and environmental factors like interference.
Q: How reliable is the UCODE HSL chip in challenging environments?
A: The UCODE HSL chip provides industry-leading RF performance and features an advanced anti-collision function, which allows a reader to communicate with multiple cards in the field at once. This ensures consistent and reliable reads for demanding applications like warehouse inventory or container tracking.
Compatibility & Technical Details Questions
Q: Are UCODE HSL cards compatible with all standard UHF readers?
A: UCODE HSL is an EPC Class 1 Gen 1 chip. Ensure your reader supports Gen 1 for compatibility.
Q: Can UCODE HSL RFID cards be used with NFC-enabled phones?
A: No, UCODE HSL operates at 860–960 MHz, incompatible with NFC’s 13.56 MHz frequency.
Ucode HSL Memory & Security
Q: How much memory does the UCODE HSL chip have?
A: It features a large 2048-bit memory, which provides ample space for storing extended product information, shipping details, or maintenance records in addition to the standard EPC code.
Q: How do UCODE HSL cards protect my data from unauthorized scanning?
A: The chip’s memory is protected by user-definable access conditions and passwords. This allows you to lock memory banks and prevent data from being overwritten or read without proper authorization. For added security in public environments, storing cards in an RFID-blocking wallet or sleeve is also recommended.
